The Sennheiser XSW 1-835-A WIRELESS 1 Vocal Set is an easy to use all-in-one wireless system for singers and presenters, excellent for live sound featuring Sennheiser's renowned evolution microphone capsule, e835 (superior dynamic, cardioid). The set includes a handheld transmitter and an intuitive stationary receiver for quick setup and hassle-free handling.

Description

Raise Your Voice

Go for XS WIRELESS 1 XSW 1-835-A and rely on a solid wireless transmission with up to 10 compatible channels in a stable UHF band (548 - 572 MHz). The XS WIRELESS 1 Vocal Set is an easy to use all-in-one wireless system for singers and presenters, excellent for live sound featuring Sennheiser's renowned evolution microphone capsule, e835 (superior dynamic, cardioid) to get started. The set includes an intuitive stationary receiver for quick setup and hassle-free handling, as well as a vocal microphone and microphone clamp.

Features

Excellent live sound featuring Sennheiser’s renowned evolution microphone capsules (e835)
Antenna-switching diversity reception
Integrated antennas
Automatic frequency management and synchronization via remote channel for easy setup
Selectable UHF frequencies within a large bandwidth (548 - 572 MHz)
Up to 10 compatible channels

Specifications

System
Modulation	Wideband FM
Frequency Range	A: 548 to 572 MHz
Switching Bandwidth	Up to 24 MHz
Frequencies	1 frequency bank with up to 10 factory-preset channels
Signal-to-Noise Ratio	≥ 103 dBA
THD	≤ 0.9 %
Temperature Range Operation	0 °C to +40 °C storage: – 20 °C to +70 °C
Transmitter Synchronization	2.4 GHz, Low Power OQPSK (only active during synchronization)
Receiver
Receiver Principle	Double superheterodyne
Diversity Principle	Antenna switching diversity via internal antennas
Sensitivity	< 3 μV at 52 dB(A)rms S/N (at peak deviation)
AF Frequency Response	80 to 16,000 Hz
Max. AF Output Voltage	(At peak deviation, 1 kHz AF) 1/4" (6.3 mm) jack socket (unbalanced): +6 dBu XLR socket (balanced): +12 dBu
Audio Adjustment Range	45 dB, adjustable in 5-dB steps
Power Supply	12 V DC nom. / 300 mA
Squelch	Adjustable from 3 dBμV to 28 dBμV (combined with pilot tone)
Line/Mic Level	20 dB, switchable
Housing Material	Rugged ABS housing
Dimensions (H x W x D)	Approx. 1.65" (42 mm) x 7.87" (200 mm) x 5" (127 mm)
Weight	Approx. 0.75 lbs
Transmitter
RF Output Power	10 mW
AF Frequency Response	80 to 14,000 Hz
Power Supply	2 AA size batteries, 1.5 V
Operating Time	Approx. 10 hours
Microphone Type	Dynamic
Input Sensitivity	1.5 mV/Pa (capsule)
Pick-Up Pattern	Cardioid
Adjustment Range of Transmitter Sensitivity	0 to – 30 dB, adjustable in 10-dB steps
Housing Material	Rugged ABS housing
Dimensions (L x Dia)	Approx. 10.23" (260 mm) x 1.9" (50 mm)
Weight	Approx. 0.54 lbs (0.245 kg)

DOCUMENTS

In The Box

(1) EM-XSW 1 Receiver
(1) SKM 835-XSW Handheld Transmitter
(1) MZQ 1 Microphone Clamp
(1) NT 12-5 CW Power Supply
(2) AA Batteries
