The Shure PGXD2/SM58 is a digital wireless handheld microphone which includes SM58 Vocal Microphone with PGXD2 Handheld Transmitter.

Description

The PGX Digital Offering tailored wireless solutions for vocalists, guitarists, and presenters, PGX Digital combines the trusted legacy of Shure microphones with state-of-the-art, 24-bit digital wireless technology that delivers strong, clean RF performance. The result is wireless audio that sounds like wired, rock-solid RF signal, and simple setup and operation.

Compatible with Shure microphones trusted by musicians for decades, including the legendary SM58, the PGXD2 transmits wireless audio with pure digital clarity and rock-solid reliability.

The legendary Shure SM58 vocal microphone is designed for professional vocal use in live performance, sound reinforcement, and studio recording. Its tailored vocal response for sound is a world standard for singing or speech. A highly effective, built-in spherical filter minimizes wind and breath "pop" noise. A unidirectional (cardioid) pickup pattern isolates the main sound source while minimizing unwanted background noise.

Rugged construction, a proven shock-mount system, and a steel mesh grille ensure that even with rough handling, the SM58 will perform consistently, outdoors or indoors.

Features

  • PGXD2 Handheld Transmitter Features:
  • Power, mute, and battery status LED.
  • Up to 9 hours of continuous use from 2 AA batteries.
  • 200 ft (60 m) operating range.
  • 10 dB of adjustable gain.
  • Lockable interface prevents accidental setting changes.
  • Rugged construction for reliable performance show after show.
  • SM58 Vocal Microphone Features:
  • Frequency response tailored for vocals, with brightened midrange and bass rolloff.
  • Uniform cardioid pickup pattern isolates the main sound source and minimizes background noise.
  • Pneumatic shock-mount system cuts down handling noise.
  • Effective, built-in spherical wind and pop filter.
  • Supplied with break-resistant stand adapter which rotates 180 degrees.
  • Legendary Shure quality, ruggedness and reliability.
  • Cardioid (unidirectional) dynamic.
  • Frequency response: 50 to 15,000 Hz.
  • Replacement cartridge: R59.

Specifications

Working Range (Line of Sight) 60 m (200 ft)
RF Carrier Range X8: 902–928 MHz;X8A: 915–928 MHz;X8B: 902–907.5 MHz, 915–928 MHz
Audio Frequency Response 20–20000 Hz
Total Harmonic Distortion
Dynamic Range >108 dB, A-weighted
Operating Temperature Range -18°C (0°F)– +50°C (122°F)
Audio Input Level +5 dBV maximum at -10 dB gain position;–5 dBV maximum at 0 dB gain position
Gain Adjustment Range 10 dB
RF Output Power 10 mW
Housing Molded PC/ABS handle and battery cup
Power Requirements 2 “AA” size alkaline or rechargeable batteries
Battery Life Up to 9 hours
Dimensions 10 X 2 in. (254 mm X 51 mm dia.)
Weight 0.769 lbs (349 g) (12.3 oz.) (without batteries)
Type Dynamic (moving coil)
Frequency Response 50–15,000 Hz
Polar Pattern Cardioid
Output Impedance EIA rated at 150Ω (300Ω actual)
Sensitivity (at 1 kHz, open circuit voltage) –54.5 dBV/Pa (1.85 mV)
Polarity Positive pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3
Connector Three-pin professional audio (XLR), male
Case Dark gray, enamel-painted, die cast metal;matte-finished, silver colored,spherical steel mesh grille
Weight 0.656 lbs (0.298 kg)
