The SLXD14+ digital wireless guitar system delivers professional 24-bit digital audio with over 118 dB of dynamic range and dependable RF stability for musicians, presenters, houses of worship, and corporate environments. With a wide 138 MHz tuning range, it supports up to 11 simultaneous systems in 6 MHz TV bands and up to 14 systems in 8 MHz bands, providing flexible deployment and consistent performance even in crowded RF conditions. Automatic Setup ensures transmitters and receivers stay connected despite interference.
ShowLink Ease technology enables remote transmitter control directly from the linked receiver, allowing frequency changes, RF power adjustments, control locking, and firmware updates over the air. System monitoring and configuration are available through Wireless Workbench desktop software or the WWB Mobile app, via Wi-Fi or Bluetooth. Built-in Shure Digital Feedback Reducer helps minimize unwanted feedback, while standard AES-256 encryption ensures secure transmission.
The system includes the WA305 Premium Instrument Cable for reliable signal integrity and durable performance. Power options include two AA batteries (included) or the optional SB903 rechargeable lithium-ion battery, delivering up to 8 hours of operation.
| SLXD4+ | |
|---|---|
| Power Requirements | 15 VDC @ 360 mA |
| Connector Type | BNC |
| Impedance | 50Ω |
| Spurious Rejection | >75 dB |
| Gain Adjustment Range | -18 to +42 dB in 1 dB steps |
| Mic/Line Switch | 30 dB pad |
| Network Interface | Single Port Ethernet 10/100 Mbps |
| Network Addressing Capability | DHCP or Manual IP address |
| Maximum Cable Length | 100 m (328 ft) |
| Dimensions (H x W x D) | 1.65" (42 mm) x 7.76" (197 mm) x 5.98" (152 mm) |
| Weight | 2 lbs (0.91 kg) |
| SLXD1+ | |
| Connector | 4-pin male mini connector (TA4M) |
| Configuration | Unbalanced |
| Impedance | 1 MΩ |
| Maximum Input Level | 8.2 dBV (2.57 Vrms, 7.27 Vpp) |
| Preamplifier Equivalent Input Noise (EIN) | –118 dBV |
| Antenna Type | 1/4 Wave |
| Occupied Bandwidth | |
| Power | 1 mW or 10 mW |
| Battery Type | Rechargeable Li-Ion or 1.5 V AA batteries |
| Housing | PC/ABS |
| Dimensions (H x W x D) | 3.86" (98 mm) x 2.68" (68 mm) x 1" (25.5 mm) |
| Weight | 0.20 lbs (0.09 kg) |
