SoundTube RS4-EZ 4" Full-Range Open-Ceiling Pendant Speaker - Black

Part #:
RS4-EZ-BK
Model #:
RS4-EZ
Availability: Limited Stock Please be aware that global supply shortages outside our control may interfere with our normal delivery times and product availability. For more information, email sales@proacoustics.com or call us at 888-256-4112.
Certified Audio
Expertise
FREE Custom
System Design
Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Get a Quote, Price or Support Fast!

We want to make contacting us as fast and as easy as possible. Please reach out if you have any questions or concerns about our products, system design, technical support, or orders.
Phone Monday - Friday
8:00 AM - 5:00 PM
1-888-256-4112
Email Contact us by email or
our simple form.
SEND EMAIL

The RS4-EZ is a 4-inch, full-range, ported speaker with an open-ceiling enclosure design. Hanging hardware is included and features a SpeedClamp™ self-locking wire grip for fast, easy and secure installation. RS4-EZ speakers utilizes the patented ZeroReflection™ enclosure technology for optimal sound reproduction and cabinet rigidity.

Description

The RS4-EZ is a 4-inch, full-range, ported speaker with an open-ceiling enclosure design. Hanging hardware is included and features a SpeedClamp™ self-locking wire grip for fast, easy and secure installation. RS4-EZ speakers utilize the patented ZeroReflection™ enclosure technology for optimal sound reproduction and cabinet rigidity. The easy access five-position selectable tap switch for 25-, 70.7- and 100-volt applications with transformer bypass position simplifies ordering and inventory tracking. The RS4-EZ speaker's average sensitivity of 90.0 dB offers high-output capabilities and reduced amplification costs. SoundTube®'s custom-engineered driver and electro-acoustic network deliver high-performance sound in a cost-effective speaker design. The RS4-EZ speaker incorporates a low-profile grille and a five-position tap switch with transformer bypass position. Euroblock connector and terminal weather boot are included.

Features

  • One 4 inch (102 mm) full-range, treated fiber driver mounted to an ABS baffle
  • Weatherized components for indoor and outdoor applications
  • Includes hanging hardware with galvanized steel cables and integrated SpeedClamp self-locking wire grip for fast, easy and secure installation
  • Patented ZeroReflection enclosure technology for optimal sound reproduction and cabinet rigidity
  • Easy access five-position selectable tap switch for 25-, 70.7- and 100-volt applications with transformer bypass position
  • Steel grille with protective powder-coated finish for lasting durability
  • Average sensitivity of 90.0 dB offers high-output capabilities and reduced amplification costs
  • UL 2239 (hanging cable) approved
  • High-quality black or white paint finish. Custom colors available
  • Optional accessory: AC-RS-SM5 bracket for surface-mount applications

Specifications

Frequency Response (-3 dB) 185 Hz - 13 kHz
Low Frequency (-10 dB) 98 Hz - 22 kHz
Sensitivity 90 dB
Power Capacity RMS 20W
Max SPL dB @ 1 M 103 dB
Nominal Impedance 8 ohms
Woofer 4" Extended-range paper cone
Full-Range Drivers 4" Full-Range
Connections Four-pin Euroblock
Dimensions (Dia x H) 7.7" (195.6 mm) x 8.8" (223.5 mm)
Weight 3.9 lbs (1.8 kg)
Shipping Weight 6 lbs (2.7 kg)
