Speco Technologies PL200M Four Zone 160W Mixer Amplifier with 5 Separate Inputs to 4 Distinct Zones
The Speco Technologies PL200M Four Zone Commercial Amplifier is the next generation of Speco Technologies' commercial amplifiers. This advanced unit features matrix technology, letting you route up to 5 separate inputs to 4 distinct zones. This allows you to simultaneously play a different source in each zone. Assigning a source to a zone is as easy as pressing a button, and each source has its own separate gain, treble, bass and volume controls. Three of the inputs feature a unique universal plug allowing for flexibility of connecting either an XLR or a 1/4" plug into the same input. Ideal for offices, hospitality, hotels and more.
- Features
Features
- Simultaneous playback of up to 5 sources into up to 4 zones
- Telephone paging function and monitor output for a limited music-on-hold function
- Microphone 1 priority with VOX mute function
- Intelligent cooling fan
- RoHS compliant
- Separate controls (gain, bass, treble, volume) and mute for each source
- Separate volume control & LED level indication for each zone
- 19" rack mount design with built-in handles (3U)
- Specification
Inputs 3 XLR / 1/4" combination inputs with phantom, mic or line level selection switch / 2 RCA inputs Outputs 4 sets of 4 ohms / 8 ohms / 25/70V RMS Power Output 40W RMS power output per zone for 160W RMS total Frequency Response 60Hz – 17kHz (±3dB) Dimensions (H x W x D) 5.2" (132.08 mm) x 19" (482.6 mm) x 12.2" (309.88 mm) Weight 33.3 lbs (15.1 kg) - Documents
