TASCAM’s MD-CD1mkIII is the only combination CD and MiniDisc solution for contractors, broadcast and other installations requiring MD-format compatibility.

Description

TASCAM’s MD-CD1mkIII is the only combination CD and MiniDisc solution for contractors, broadcast and other installations requiring MD-format compatibility. Based on the best-selling MD-CD1, the new model adds new digital I/O, additional file playback from CD, an expanded pitch range for CD playback and more. For space-challenged jobs that need a variety of playback options, the MD-CD1mkIII is the perfect choice.

The CD player on the MD-CD1mkIII supports MP3 and WAV file playback in addition to standard CD or CD-TEXT discs. The MiniDisc can play or record in all major formats: SP, MONO, LP2, and LP4. Discs can be dubbed from CD to MiniDisc at up to 4x speed, and continuous playback can cycle from one transport to the other. Both the CD and MiniDisc include Auto Cue and Auto Ready functions.

On the rear panel, each transport has its own set of unbalanced outputs, plus coaxial and optical S/PDIF digital outs. The MiniDisc section has unbalanced inputs, coaxial and optical digital inputs as well. An optional balancing kit, the LA-MC1, adds XLR balanced I/O to the MD-CD1mkIII. It can be controlled using RS-232C, wireless remote control, or a PS/2 keyboard.

Packing hours of playback in only two rack spaces, the MD-CD1mkIII is the ultimate solution for cramped installations requiring the flexibility of MiniDisc.

Features

CD Features:

Applicable discs: audio CD / CD-R / CD-RW / CD-ROM (MP3/WAV)
CD-text display (Stop: Disc title, Play: Track title)
ID3 tag display (Song title)
-50 to +16% pitch control with selectable steps (0.1 to 1%) for audio CD
+/-6 semi-tone key control in semi-tone steps for audio CD
Key control without affecting playback speed
Various playback modes: all / single / program (up to 99 tracks) / random
Various repeat modes: all / single / program (up to 99 tracks) / random / A-B
Auto cue (-72 to -24 dB in 6 dB steps)
Auto ready
Digital volume on output (-infinity, -54 to +18 dB)
Fade in/out playback (1 to 30 seconds in 1 second steps)
EOM (End of message) for indicating the end of track or disc (1 to 99 seconds in 1 second steps)
Time search by numeric keys on remote controller
Power on play
Time display mode: track elapsed / track remain / disc elapsed / disc remain (When playing the MP3 file or WAV file: track elapsed)
Directory play mode for MP3 discs or WAV discs
RCA unbalanced analog output
S/PDIF optical digital output
S/PDIF coaxial digital output
Remote control by PS/2 keyboard

MiniDisc Features:

Supports SP (stereo) / MONO / LP2 / LP4 modes
Recording in different mode (ST/MONO/LP2/LP4) in the disc and playback the disc which contains the different mode of the song is possible
Edit functions: erase, divide, combine, move, title
Grouping function and group playback
Overwrite
Auto track increment with input audio level and track information data from S/PDIF input
Manual Track increment by pressing the record button during recording
Sync recording by input audio signal
Input monitor
Digital volume on input (-infinity, -54 to +18 dB)
Fade in and out recording (1 to 30 seconds in 1 second steps)
Pre recording (off, 1 to 6 seconds in 1 seconds steps)
Various playback modes: all / single / program (up to 25 tracks) / random / group
Various repeat modes: all / single / program (up to 25 tracks) / random / A-B
Auto cue
Auto ready
EOM (End of message) for indicating the end of track or disc (1 to 99 seconds in 1 second steps)
Time search by numeric keys on remote controller
Power on play
Time display mode: track elapsed / track remain / disc elapsed / disc remain
RCA unbalanced analog input and output
S/PDIF optical digital input and output (SCMS)
S/PDIF coaxial digital input and output (SCMS)
Remote control, editing, and title input by PS/2 keyboard

Combined Features:

COMMON output for CD and MD output (priority can be set)
Headphone output with selectable source (MD, CD, or common)
Dubbing from CD to MD (whole disc or track by track):
4 x: in SP mode
2 x: in MONO / LP2 / LP4 mode
1 x: from MP3 or WAV discs and when CD's pitch control/key control on
Continuous playback between MD and CD (no limitation)
Independent operation of MD and CD
Auto title input from CD-text and ID3 tag
Wireless remote controller
RS-232C serial remote control
LA-MC1 optional balanced I/O card
2U rack mount size

Specifications

Input Ratings (MD Inputs)
Type	MiniDisc recorder
Discs	MiniDisc format
Number of Channels	2 channels (stereo)/1 channel (mono)
Rec Modes	Stereo/Mono/LP2/LP4
Recording Format	Magnetic field modulation overwrite
Sampling Frequency	44.1 kHz
Compression System	ATRAC (Adaptive Transform Acoustic Coding)
Type	Compact Disc player
Discs	CD-DA (12 cm/8 cm), CD-ROM (12 cm/8 cm), CD/CD-R/CD-RW
File System	ISO9660 LEVEL 1/2/ROMEO/JOLIET format
Formats	Audio CD (CD-DA), MPEG Audio Layer III (MP3), WAV
Audio CD Playback	Sampling frequency: 44.1 kHz, Quantization bit rate: 16 bit, Number of channels: 2
Audio Modes	STEREO, JOINT STEREO, DUALCHANNEL, MONO
Sampling Frequency	44.1 kHz
Bit Rate	32 kbps - 320 kbps, or VBR
Sampling Frequency	44.1 kHz
Quantization Bit Rate	16 bit
Connector	RCA pin jack
Input Impedance	22 kΩ
Nominal Input Level	–10 dBV (0.32 Vrms)
Maximum Input Level	+6 dBV (2.0 Vrms)
Minimum Input Level	–22 dBV (0.08 Vrms)
Connector	RCA pin jack
Format	IEC-60958-3 (S/PDIF, conformingto SCMS)
Sampling Frequency Range	32 kHz - 48 kHz
Connector	TOS (JEITA RC-5720C)
Format	IEC-60958-3 (S/PDIF, conformingto SCMS)
Output Ratings
Connector	RCA pin jack
Output Impedance	200Ω
Nominal Output Level	–10 dBV (0.32 Vrms)
Maximum Output Level	+6 dBV (2.0 Vrms)
Connector	6.3 mm stereo standard jack.
Maximum Output	20 mW + 20 mW (1 kHz, 0.1%, 32Ω)
Connector	RCA pin jack
Compatible Signal Format	IEC-60958-3 (S/PDIF,conforming to SCMS)
Connector	TOS (JEITA RC-5720C)
Format	IEC-60958-3 (S/PDIF, conformingto SCMS)
Frequency Response	20 Hz - 20 kHz ±0.5 dB (CD playback, JEITA) 20 Hz - 20 kHz ±0.5 dB (MD playback, JEITA) 20 Hz - 20 kHz ±0.5 dB (MD recording/playback, JEITA)
S/N Ratio	100 dB or more (CD plybk, JEITA) 98 dB or more (MD plybk, JEITA) 95 dB or more (MD rec/plybk, JEIT
Total Harmonic Distortion	0.004% or less (CD plybk, JEITA) 0.004% or less (MD plybk,JEITA) 0.006% or less (MD rec/plybk,JEIT
Dynamic Range	100 dB or more (CD plybk,JEITA) 98 dB or more (MD plybk,JEITA) 95 dB or more (MD rec/plybk,JEITA)
Channel Separation	90 dB or more (CD plybk, JEITA) 90 dB or mer (MD plybk, JEITA) 83 dB or more (MD rec/plybk, JEITA)
Power	120 VAC, 60 Hz
Power Consumption	22W
Operation Temperature Range	5 - 40°C
Dimensions (H x W x D)	3.7" (94 mm) x 19" (483 mm) x 12.1" (308 mm)
Weight	11.9 lbs (5.4 kg)
