The DLT 400-AIM is a portable, professional digital interpretation transceiver designed for effortless multilingual communication. Equipped with the Digi-Wave Advanced Interpretation Module (AIM), it supports 24 channels, the highest among comparable systems, and provides crystal-clear digital audio across multiple speakers and listeners.
Interpretation is simplified with the Q&A mode, allowing interpreters to switch between two languages during panel discussions or live Q&A sessions, while supporting multiple active microphones per language. The system also enables administrators to customize channel names to up to 5 characters, select from 100 ISO language codes, organize subgroups, and manage programming offline using the control function. Every system includes at least one DLT 400-AIM two-way transceiver and is compatible with existing Digi-Wave 400 receivers running firmware 1.3.0 or higher.
This versatile transceiver is ideal for government courtrooms, corporate training sessions, guided tours, healthcare facilities, and educational settings, providing reliable, interference-free performance with a frequency-hopping algorithm to maintain consistent, high-quality digital audio.
| System Voltages | OLED 14VDC; RF 5VDC; Logic 3.3VDC |
|---|---|
| Operating Frequencies | 2.4 GHz ISM band, 2402 - 2476 MHz FHSS |
| Audio Frequency Response | Interpretation/Tour/Hearing Assist: 100 - 11,500 Hz; Other Modes: 100 - 7,200 Hz |
| Signal-to-Noise Ratio (SNR) | 73 dB (A-weighted, default Rx volume with mic input) |
| Total Harmonic Distortion (THD) | 0.1 % (Default volume, 1 kHz) |
| Microphone Input | Internal mic + 3.5 mm electret input, adjustable gain 63 dB |
| Line Input | USB-C, adjustable level |
| Headphone Output | 3.5 mm TRRS, 25 mW into 32Ω |
| Range | Up to 900 ft (274 m), depending on environment |
| Security | 87-bit encryption (300 Series Compatible), 128+87 bit encryption, PIN, settings lock |
| Indicators | OLED display, bi-color LED top, red LED around talk button |
| Battery Type | Lithium Polymer with smart charge built into transceiver, 1800 mAH |
| Battery Life | Up to 16 hours talk time per charge (1ch Tx / 1ch Rx) |
| Charge Time | Approx. 5 hours |
| Case Material | Black ABS Plastic |
| Color | Black (Front/Back) |
| Dimensions (H x W x D) | 4.22" (107.3 mm) x 2.60" (66 mm), 0.50" (12.6 mm) |
| Weight | 0.21 lbs (0.10 kg) |
