The Yamaha CW218V dual 18" subwoofer features refinements aimed at permanent installations.

Description

The Yamaha Club V loudspeakers with the C prefix are coated with a heavy-duty elastomeric spray coating. Designed as an installation alternative to the carpeted S versions. The finish is very tough, and readily paintable to match surroundings. The steel grilles are foam-lined with acoustically transparent material to provide a more subdued appearance. Once again, with professional features, excellent sonic performance and great value, Club Series loudspeakers deliver premium quality night after night. Cabinets are constructed of high quality particleboard, chosen for its high strength and elasticity, consistent void free makeup and light weight. Another great benefit of this material is its environmental friendliness. Made from southern yellow pine, this material is both abundant and quickly renewable. Accurate CNC routing machines are used to cut every part, assuring consistency with tolerances of one ten thousandth of an inch. Skilled technicians assemble each cabinet by hand, rejecting any defects. Whether covered in durable carpet or the elastomeric spray coating, heavy steel handles and sturdy pole sockets make moving and positioning easy. Crossover networks that divide the signal going to the woofer and compression driver are constructed with oversized coils, high voltage capacitors, and power resistors designed to provide the best possible sound quality and minimize loss. Overload protection is also included to protect the components.

Features

  • Dual 18" subwoofer
  • Unique folded baffle design
  • Low-profile cabinet
  • Capable of extreme SPL
  • Heavy-duty elastomeric spray coating

Specifications

Speaker Type Dual 18" subwoofer
Frequency Response 30Hz - 2kHz
Components (LF) 2 x 18" cone
Power Rating NOISE: 600W (EIA); PGM: 1200W; PEAK: 2400W
Nominal Impedance 4 Ohms
Sensitivity (1W; 1m on axis) 98 dB SPL
Continuous (Calculated) 126 dB SPL
Peak (Calculated) 132 dB SPL
I/O Connectors 2x Phone, 2x SpeakON
Finish Sprayed finish
Dimensions (H x W x D) 22.6" (574 mm) x 47.9" (1217 mm) x 25.79" (655 mm)
Weight 142.7 lbs (64.7 kg)
