Yamaha DZR12W 12-Inch Powered White Loudspeaker

The DZR12W delivers exceptional clarity and professional-grade sound in a compact, lightweight package. This white 12-inch, 2-way bi-amplified powered loudspeaker achieves an impressive 139 dB SPL and a wide 39 Hz to 20 kHz frequency range, ensuring superb low-frequency response and crystal-clear high-frequency performance. With advanced DSP processing and best-in-class SPL, the DZR12W is ideal for live sound, touring, and installed audio systems.

Equipped with a 2000W Class-D amplifier and 96 kHz DSP with FIR filters, the DZR12W provides high-resolution sound with ultra-low latency. Yamaha's Advanced FIR-X tuning minimizes phase distortion, while D-Contour processing and robust protection circuits maintain consistent performance under demanding conditions. The intuitive LCD display allows precise adjustments of PEQ, delay, routing, and presets for complete control over your sound.

Designed for versatility, the DZR12W features a rotatable horn, floor monitor capability, and flexible U-bracket rigging options. Its durable white Polyurea-coated plywood cabinet ensures reliability and long-term use, while the optional SPCVR-DZR12 speaker cover provides extra protection during transport or storage. Combining power, clarity, and ruggedness, the DZR12W is a top choice for professional audio applications.

Features

Features

White 12" 2-way bi-amplified powered loudspeaker
2000W Class-D amplifier module for high-output performance
Maximum 139 dB SPL with 39 Hz to 20 kHz frequency range
96 kHz DSP with FIR filters for high-resolution sound
Advanced FIR-X tuning minimizes phase distortion
D-Contour processing and reliable protection circuits
Rotatable horn and flexible U-bracket mounting options
Floor monitoring setting for mirrored setup
Lightweight yet rugged white Polyurea-coated cabinet
Optional SPCVR-DZR12 protective speaker cover
Precise DSP control via intuitive LCD interface
Ideal for live sound, touring, and installed applications

Specification

Speaker Type	2-way, Bi-amped Powered Speaker, Bass-reflex
Frequency Range (-10 dB)	39 Hz - 20 kHz
Coverage Area	H90° x V60° (Rotatable)
Components	LF: 12" Cone, 3" Voice Coil, Neodymium magnet HF: 2" Voice Coil, 1" Throat Compression Driver, Titanium diaphragm, Neodymium magnet
Crossover	1.8 kHz (FIR-X)
Sampling Frequency Rate	Internal: 96 kHz and FIR Filter
A/D D/A Converters	96 kHz AD/DA
Maximum Output Level (1 m; on axis)	139 dB SPL
Power Rating	Dynamic: 2000W (LF: 1000W, MF/HF: 1000W) Burst (20ms): 1100W (LF: 1000W, MF/HF: 100W) Continuous: 950W (LF: 850W, MF/HF: 100W)
I/O Connectors	Analog IN: Combo x 2, Line level (Maximum +24 dBu), Input impedance 20 kΩ Analog OUT: XLR3-32 x 2, CH1: THRU (fix), CH2: THRU or DSP OUT
AC	IEC AC inlet x 1 (V-Lock)
Amplifier Class	Class-D
Cooling	Fan cooling, Variable speeds
Power Consumption	45W (Idle), 150W (1/8)
Handle	Aluminium die-cast, Side x 2
Rigging	M10 x 12
Floor Monitor Angle	50° Symmetrical
Pole Socket	35 mm x 2 (0° or -7°)
Finish	Plywood, Durable Polyurea Painting, White
Dimensions (H x W x D)	25.4" (646 mm) x 16.1" (410 mm) x 15.5" (394 mm)
Weight	47.2 lbs (21.4 kg)
