Yamaha DZR15W 15-Inch Powered White Loudspeaker

The DZR15W is a high-performance 2-way bi-amped powered loudspeaker designed to deliver exceptional sound quality and impressive output levels. Finished in clean, modern white, it produces a remarkable maximum SPL of 139 dB with outstanding clarity and deep, controlled low-frequency reproduction. Its combination of power and precision makes it an excellent choice for demanding professional audio applications, from live performances to fixed installations.

Advanced 96 kHz DSP processing and Yamaha's FIR-X tuning technology ensure phase-coherent sound and accurate imaging, even at high volume. Engineers can access detailed control via the intuitive LCD display, adjusting PEQ, delay, and routing to fine-tune performance. The DZR15W also includes D-Contour multi-band compression and highly reliable protection circuitry for consistent, dependable operation.

Housed in a lightweight yet durable plywood cabinet coated with premium Polyurea, the DZR15W is built to withstand rigorous use. Its rotatable horn, dual-angle pole socket, floor monitor mode, and optional U-brackets allow flexible deployment in a wide range of environments. Whether used on stage or in a refined installation, the DZR15W delivers the professional power and sonic detail that modern audio workflows demand.

Features

Features

White 2-way bi-amped powered loudspeaker with 15" LF and 2" HF drivers
Up to 139 dB maximum SPL with a 34 Hz to 20 kHz frequency range
High-power 2000W Class-D amplifier module
96 kHz DSP and FIR-X tuning for high-resolution, phase-coherent sound
Intuitive LCD display for DSP control, presets, PEQ, delay, and routing
D-Contour processing and advanced protection circuitry
Floor monitor mode with mirroring configuration
Lightweight, rugged plywood enclosure with premium Polyurea coating
Rotatable horn and U-bracket options for flexible mounting
Optional protective cover (SPCVR-DZR15)

Specification

Speaker Type	2-way, Bi-amped Powered Speaker, Bass-reflex
Frequency Range (-10 dB)	34 Hz - 20 kHz
Coverage Area	H90° x V50° (Rotatable)
Components	LF: 15" Cone, 3" Voice Coil, Neodymium magnet HF: 2" Voice Coil, 1" Throat Compression Driver, Titanium diaphragm, Neodymium magnet
Crossover	1.7 kHz (FIR-X)
Sampling Frequency Rate	Internal: 96 kHz and FIR Filter
A/D D/A Converters	96 kHz AD/DA
Maximum Output Level (1 m; on axis)	139 dB SPL
Power Rating	Dynamic: 2000W (LF: 1000W, MF/HF: 1000W) Burst (20ms): 1100W (LF: 1000W, MF/HF: 100W) Continuous: 950W (LF: 850W, MF/HF: 100W)
I/O Connectors	Analog IN: Combo x 2, Line level (Maximum +24 dBu), Input impedance 20 kΩ Analog OUT: XLR3-32 x 2, CH1: THRU (fix), CH2: THRU or DSP OUT
AC	IEC AC inlet x 1 (V-Lock)
Amplifier Class	Class-D
Cooling	Fan cooling, Variable speeds
Power Consumption	45W (Idle), 150W (1/8)
Handle	Aluminium die-cast, Side x 2
Rigging	M10 x 12
Floor Monitor Angle	50° Symmetrical
Pole Socket	35 mm x 2 (0° or -7°)
Finish	Plywood, Durable Polyurea Painting, White
Dimensions (H x W x D)	30" (761 mm) x 17.7" (450 mm) x 18.1" (460 mm)
Weight	55.6 lbs (25.2 kg)
