The Yamaha VC4N in black is a 4" 2-way coaxial ceiling speaker with 160° coverage and no back can. Its low-profile design, 16Ω/70V–100V compatibility, and secure mounting make it ideal for commercial BGM and paging installations.

Description

Yamaha VC4N 4-Inch 2-Way Black Coaxial Ceiling Speaker

The VC4N 4" 2-way coaxial ceiling speaker in black delivers premium-sounding audio at an affordable price for commercial installations. Engineered for background music and voice reproduction, its 2-way design features a 4" woofer and 0.8" tweeter, providing clear, balanced sound with wide 160° coverage across any space.

Designed without a back can, the VC4N features a slim, low-profile housing that fits easily into tight ceiling cavities. Its versatile support for low-impedance (16½) or high-impedance (70V/100V) systems allows multiple speakers to be connected efficiently, making it ideal for distributed audio setups in offices, restaurants, retail spaces, and hospitality environments.

Installation is fast and secure thanks to double-threaded speaker clamps and non-slip treads. The paintable magnetic grille blends seamlessly with ceilings, and the speaker is available in black or white to match any interior. Lightweight and compact, the VC4N combines high-quality sound, flexible installation, and modern aesthetics.

Features

  • 4" 2-way coaxial ceiling speaker with 0.8" tweeter
  • Wide 160° coverage for even sound distribution
  • No back can, low-profile design for limited ceiling spaces
  • Dual-mode operation: 16Ω low-impedance or 70/100V high-impedance
  • Ideal for multi-speaker low-impedance systems
  • Fast, secure mounting with double-threaded clamps
  • Paintable black magnetic grille for seamless ceiling integration
  • Single-unit packaging for flexible system design
  • Engineered for clear BGM and voice reproduction
  • Perfect for commercial, hospitality, office, and retail applications

Specifications

System Type 2-way Coaxial type (without backcan)
LF Driver 4" Cone
HF Driver 0.8" Film dome
Frequency Range (-10 dB) 85 Hz - 20 kHz
Coverage Angle (H x V) 160° conical
Nominal Impedance 16Ω
Transformar Taps 70V: 6W, 3W, 1.5W, 0.8W
100V: 6W, 3W, 1.5W
Power Rating NOISE: 15W, PGM: 30W, MAX: 60W
Sensitivity (1W, 1m) 88 dB SPL
Maximum SPL 106 dB SPL
Connectors 1 x Push terminal (WAGO 294 /2 pin)
Material, Finish, Color VC4B: Black (approx. Munsell N3)
Packaging Single
Certificate CE, RoHS
Required Ceiling Board Thickness 2 mm - 37 mm
Dimensions (Dia x D) 8.86" (225 mm) x 4.06" (103 mm)
Weight 3.1 lbs (1.4 kg)
