Yorkville YX12MC Stage Monitor (Discontinued)

Part # YX12MC
Model # YX12MC
The Yorkville YX12M compact Stage Monitor delivers outstanding performance in a highly cost effective package.
Description

Details

The YX12M uses a single 12-inch driver and an injection molded 90° x 30° ABS Waveguide horn with 1-inch throat and 1.4-inch Celestion neodymium compression driver. Yorkville's tried and true dual-bulb CTL™ protection system protects the horn driver's aluminum diaphragm ensuring unmatched reliability in the field. The YX12 is built road-ready with easy-to-clean, durable black carpet covering, solid internal plywood bracing and reinforced internal component mounts.

Designed with working musicians in mind, the YX12M uses a rugged 5/8-inch plywood cabinet construction, metal input plate, and a custom punched, perforated metal grille to protect the speaker components.
Features

Features

  • 200 Watt Stage Monitor
  • 12-inch Woofer
  • 1-inch Compression Driver (1.4-inch voicecoil)
  • Dedicated Wedge Monitor shape
  • Low Profile Cabinet Design
  • 90° x 30° Injection Molded ABS Waveguide Horn
  • Innovative Dual Bulb CTL™ High Frequency Driver Protection
  • 2 Speakon™ and 2 1/4-inch Paralleled Inputs
  • Solid 5/8-inch (15mm) Plywood Construction
Specification
System Type2-Way
Active or PassivePassive
Program Power (Watts)200
BiampableNo
Max SPL (dB)122
Driver Configuration12 inch / 1.4 inch
HF Driver(s)1.4 inch Aluminum (1 inch Throat)
HF HornInjection Molded ABS
HF Dispersion ( DEG H x DEG V)90 x 30
HF ProtectionCTL™
LF Driver(s)12 inch Ceramic
LF Program Power(Watts)200
Inputs - 1/4 IN Jacks2
Inputs - Speakon 4-pin2
CornersMetal
FeetPlastic Glides
Strap Handles1
Enclosure Materials15mm (5/8inch) Plywood
GrilleCustom Punched Black Perforated Metal
Covering / FinishBlack Ozite
Dimensions17.75" (450.85 mm) x 19.5" (495.3 mm) x 24" (609.6 mm) x backW 16" (406.4 mm)
Weight33 lbs (15 kg)
