The Denon DN-312X provides individual level control for all inputs in addition to level control for the mono output port and a master level control and can be powered from standard AC or 24V DC power source.

Description

Denon DN-312X 12-Channel Line Mixer with Priority

The DN-312X is an ultra-slim 1U rack-mounted 12-channel mixer with 6 mic/line combination inputs (HDHQ™ Denon-Marantz proprietary mic pre's) and 6 additional line inputs. It has balanced XLR outputs, a 1/4" (6.3 mm) mono output that can be used to connect the DN-312X to a remote mixer, a pair of RCA stereo outputs to connect to a remote recording device, and 1/4" (6.3 mm) mic monitoring port that can be used to monitor the mics' signals. The DN-312X provides individual level control for all inputs in addition to level control for the mono output port and a master level control. It has a 3-level equalizer and a controlled priority for Mic/Line 1. It can be powered from standard AC or 24V DC power source.

Features

6 HDHQ™ Combination inputs with MIC, Phantom and Line selector switches
6 mono (3 stereo) RCA Inputs
Mic monitor 1/4" output for private listening to all mic inputs
Balanced XLR line outputs
Mono 1/4" line output can be used to feed audio to external recording device
AC or 24V DC power inputs
Mic 1 Priority Control
Master and Individual level controls
1U rack mountable

Specifications

Microphone Input: 6 Balanced XLR Connectors (Channels 1–6)
Frequency Response	20 Hz - 22 kHz
THD+N	< 0.03% @ 1 kHz
Sensitivity	-40 dBu
Maximum Input	-19 dBu
Maximum Voltage Gain	60 dB (Mic Input to Line Out, Mic Out & Mono Out) 50 dB (Mic Input to Rec Out)
Signal-to-Noise Ratio	> 103 dB
Phantom Power	18–21 V, switch control
Line Inputs: 6 Balanced XLR Connectors (Channels 1–6)
Frequency Response	20 Hz - 22 kHz
THD+N	< 0.03% @ 1 kHz
Sensitivity	0 dBu
Maximum Input	+21 dBu
Maximum Voltage Gain	20 dB (Mic Input to Line Out, Mic Out & Mono Out) 10 dB (Mic Input to Rec Out)
Signal-to-Noise Ratio	> 103 dB
Line Inputs: Stereo Balanced RCA Connectors (Channels 7/8-11/12)
Frequency Response	20 Hz - 22 kHz
THD+N	< 0.03% @ 1 kHz
Sensitivity	+10 dBu
Maximum Input	+21 dBu
Maximum Voltage Gain	10 dB (Line Input to Line Out) 0 dB (Line Input to Rec Out) 4 dB (Line Input to Mono Out)
Signal-to-Noise Ratio	> 103 dB
Impedance
Mic/Line Input	1.4 kΩ
Line Input	> 10 kΩ
All Outputs	120 Ω
Equalizer
High	+15 dB @ 12 kHz
Mid	+12 dB @ 2.5 kHz
Low	+15 dB @ 80 Hz
Crosstalk
Adjacent Inputs	< -70 dB @ 1 kHz (Channels 1–6) < -68 dB @ 1 kHz (Channels 7/8–11/12)
Input to Output	< -82 dB @ 1 kHz
Main Mix
Line Output	0 dBu (+2 dBu), balanced
Mic Output, Mono Output	0 dBu (+2 dBu), unbalanced
Maximum Output	+21 dBu balanced/unbalanced, 1/4” (6.35 mm) jacks
Noise (Bus)	< -83 dB @ 20 Hz – 22 kHz
Power
Connection	IEC
Input Voltage	110-120 V AC, 60 Hz
Dimensions (H x W x D)	1.7" (44 mm) x 19" (483 mm) x 7.7" (195 mm)
Weight	6.4 lbs (2.9 kg)
