Mackie ProFX22v2 22-Channel 4-Bus Effects Mixer with USB (Discontinued)

Mackie ProFX22v2 22-Channel 4-Bus Effects Mixer with USB (Discontinued)

Name: Mackie ProFX22v2 22-Channel 4-Bus Effects Mixer with USB (Discontinued)
Brand: Mackie
SKU: MACKIE-2044604-00
Price: 699.99 USD
Availability: OutOfStock

Write a Review

Part #:

2044604-00

Model #:

ProFX22v2

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The Mackie ProFX22v2 is a 22-channel 4-bus mixer with USB that features 16 Vita™ preamps for unmatched sound quality and a no-compromise live mixing toolkit including the powerful ReadyFX™ effects engine.

Description

Mackie ProFX22v2 22-Channel 4-Bus Effects Mixer with USB
Vita™ Preamps & ReadyFX™ Effects Engine for Live Sound Applications

The Mackie ProFX22v2 22-channel 4-bus effects mixer provides a comprehensive live sound solution perfect for performing bands and other mid-sized applications. Delivering unmatched sound quality and performance, the Mackie ProFX22v2 features 16 all-new Mackie Vita™ preamps, which are virtually noiseless and designed specifically for the highly-dynamic world of live sound.

ProFX22v2 also includes the immensely powerful new ReadyFX™ effect engine, harnessing floating-point DSP to deliver 16 rich effects that elevate any performance. A no-compromise live sound toolkit includes GEQ, dedicated inline channel compression and a built-in USB interface for hassle-free recording/playback. With a rugged steel chassis and unmatched sonic performance, ProFX22v2 is truly the life of your live mix.

The Mackie ProFX22v2 is a replacement for the Discontinued Mackie ProFX22.

Features

16 extremely low-noise Mackie Vita™ mic preamps designed to add life to any input
All-new ReadyFX™ effects engine with 16 great-sounding effects like reverbs, delays and choruses
Single-knob channel compression for smooth, even dynamic control (ch. 11-14)
7-band graphic EQ for tuning mains or monitors
Built-in USB interface to record the show or provide music playback
4 flexible subgroups for professional mix management
2 aux outputs for monitor mixes, fill speakers and more
3-band EQ with sweepable mids on mono channels
22 high-headroom line level inputs
Individual channel mutes and overload indication
100Hz low-cut filters per channel (18dB/octave)
Channel inserts for connecting outboard processing (ch. 1-10)
60 mm faders for input channels, subgroups and main masters
48V phantom power for connecting condenser mics
FX mute with remote control via footswitch
Break switch mutes all channels for music playback between sets
Control room / headphone outs with level control
Balanced XLR and balanced/unbalanced 1/4" main outputs
Built-in USB recording interface with simple setup via Mac or PC

Choose to record subgroups 1/2 or main L/R mix
Separate USB input level control to mains
USB routable to full-featured channel strip

Great for live recording and perfect for home studios
Stream playback music for live or studio applications
Includes user-friendly Tracktion® recording software
Legendary Mackie “Built-Like-A-Tank” design
Solid steel chassis protects your investment
Tough ABS side protection
Robust internal multi-voltage power supply

Specifications

Noise Characteristics
Mic In to Insert Send Out (Max Gain)	–128 dBu
All Outputs, Master Levels Unity, All Channel Levels Off	–85 dBu
Frequency Response
Mic Input to Any Output	20 Hz to 40 kHz (gain at unity, +0 dB / –1 dB)
Distortion (THD+N)
Mic In to Main Out
Attenuation and Crosstalk
Adjacent Inputs @ 1 kHz	–90 dB
Inputs to Outputs @ 1 kHz	–80 dB
Fader Off @ 1 kHz	–75 dB
Mute Switch / Break Switch Mute @ 1 kHz	–100 dB
Common Mode Rejection Ratio (CMRR)
Mic In to Main Out	70 dB (max gain, 1 kHz)
Maximum Levels
All Inputs	+22 dBu
Main Out XLR	+28 dBu
All Other Outputs	+22 dBu
Impedances
Mic In	3.3 kΩ
Channel Insert Return	10 kΩ
All Other Inputs	≥ 20 kΩ
Tape Output	1 kΩ
Phones Output	25 Ω
All Other Outputs	120 Ω Unbalanced, 240 Ω Balanced
Equalization
Low	±15 dB @ 80 Hz
Mid	±15 dB
High	100 Hz – 8 kHz
Low Cut Filter	18 dB/octave @ 100 Hz
Low	±15 dB @ 80 Hz
Mid	±15 dB @ 2.5 kHz
High	±15 dB @ 12 kHz
Dimensions (H x W x D)
Product	3.8" (97 mm) x 25.1" (639 mm) x 16" (407 mm)
Shipping	8.1" (206 mm) x 28.4" (721 mm) x 20.4" (518 mm)
Weight
Net	18 lbs (8.2 kg)
Shipping	24.5 lbs (11.1 kg)
