Mackie ProFX8v2 8 Channel Professional Effects Mixer with USB (Discontinued)

By Mackie

Mackie ProFX8v2 8 Channel Professional Effects Mixer with USB (Discontinued)

Name: Mackie ProFX8v2 8 Channel Professional Effects Mixer with USB (Discontinued)
Brand: Mackie
SKU: MACKIE-2044601-00
Price: 219.99 USD
Availability: OutOfStock

Write a Review

Part #:

2044601-00

Model #:

ProFX8v2

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The Mackie ProFX8v2 is a replacement for the Discontinued Mackie ProFX8. Mackie’s ProFX8v2 8-channel mixer features all-new Vita™ preamps for unmatched sound quality and a no-compromise live mixing toolkit including the all-new, immensely powerful ReadyFX™ effects engine.

Description

The Mackie ProFX8v2 is a replacement for the Discontinued Mackie ProFX8.

The Mackie ProFX8v2 8-channel effects mixer provides a comprehensive live sound solution perfect for smaller performances that demand high-quality audio. Delivering unmatched sound quality, ProFX8v2 features all-new Mackie Vita™ preamps, which are virtually noiseless and designed specifically for the highly-dynamic world of live sound. ProFX8v2 also includes the immensely powerful new ReadyFX™ effects engine, harnessing floating-point DSP to deliver 16 rich effects that elevate any performance. A no-compromise live sound toolkit includes a room-shaping GEQ, flexible I/O and a built-in USB interface for hassle-free recording/playback. With a rugged steel chassis and unmatched sonic performance, ProFX8v2 is truly the life of your live mix.

Features

4 extremely low-noise Mackie Vita™ mic preamps designed to add life to any input
All-new ReadyFX™ effects engine with 16 great-sounding effects like reverbs, delays and choruses
7-band graphic EQ for tuning mains or monitors
Built-in USB interface to record the show or provide music playback
Aux output perfect for driving a monitor mix
3 stereo channels plus extra stereo return for external effects or stereo playback devices
60 mm faders for input channels, return and main/monitor masters
3-band EQ (80Hz, 2.5kHz and 12kHz) on all channels
Directly connect guitar, bass and other instruments via Hi-Z input
Insert, 100Hz low-cut filter and 48V phantom power on all mic channels
Stereo RCA tape I/O with input level control
Headphone output with separate level control
Balanced XLR and balanced/unbalanced 1/4-inch main outputs
FX mute with remote control via footswitch
Break switch mutes all channels for music playback between sets
Built-in USB recording interface with simple setup via Mac or PC
Great for live recording and perfect for home studios
Stream playback music for live or studio applications
Includes user-friendly Tracktion® recording software
Legendary Mackie “Built-Like-A-Tank” design
Solid steel chassis protects your investment
Tough ABS side protection
Robust internal multi-voltage power supply

Specifications

Noise Characteristics
Mic In to Insert Send Out (Max Gain)	–125 dBu
All Outputs, Master Levels Unity, All Channel Levels Off	–80 dBu
Frequency Response
Mic Input to Any Output	20 Hz to 30 kHz (gain at unity, +0 dB / –1 dB)
Distortion (THD+N)
Mic In to Main Out
Attenuation and Crosstalk
Adjacent Inputs @ 1 kHz	–90 dB
Inputs to Outputs @ 1 kHz	–80 dB
Fader Off @ 1 kHz	–75 dB
Mute Switch / Break Switch Mute @ 1 kHz	–90 dB
Common Mode Rejection Ratio (CMRR)
Mic In to Main Out	70 dB (max gain, 1 kHz)
Maximum Levels
All Inputs	+22 dBu
Main Out XLR	+28 dBu
All Other Outputs	+22 dBu
Impedances
Mic In	3.8 kΩ
Channel Insert Return	10 kΩ
All Other Inputs	≥ 20 kΩ
Tape Output	1 kΩ
Phones Output	25 Ω
All Other Outputs	120 Ω Unbalanced, 240 Ω Balanced
Equalization
Low	±15 dB @ 80 Hz
Mid	±15 dB @ 2.5 kHz
High	±15 dB @ 12 kHz
Low Cut Filter	18 dB/octave @ 100 Hz
Dimensions (H x W x D)
Product	3.6" (91 mm) x 11.4" (290 mm) x 14.1" (358 mm)
Shipping	7" (178 mm) x 15.6" (396 mm) x 17.9" (455 mm)
Weight
Net	7.1 lbs (3.2 kg)
Shipping	10 lbs (4.5 kg)
