Mackie ProFX4v2 4 Channel Professional Effects Mixer (Discontinued)

By Mackie

Mackie ProFX4v2 4 Channel Professional Effects Mixer (Discontinued)

Name: Mackie ProFX4v2 4 Channel Professional Effects Mixer (Discontinued)
Brand: Mackie
SKU: MACKIE-2044600-00
Price: 149.99 USD
Availability: OutOfStock

Write a Review

Part #:

2044600-00

Model #:

ProFX4v2

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Mackie’s ProFX4v2 4-channel mixer features all-new Vita™ preamps for unmatched sound quality and a no-compromise live mixing toolkit including the all-new, immensely powerful ReadyFX™ effects engine.

Description

The Mackie ProFX4v2 4-channel effects mixer provides a comprehensive live sound solution for singer/songwriters and other low channel count applications. Delivering unmatched sound quality, the ProFX4v2 features all-new Mackie Vita™ preamps, which are virtually noiseless and designed specifically for the highly-dynamic world of live sound. ProFX4v2 also includes the immensely powerful new ReadyFX™ effects engine, harnessing floating-point DSP to deliver 16 rich effects that elevate any performance. A no-compromise live sound toolkit includes a room-shaping GEQ and flexible I/O for professional applications. With a rugged steel chassis and unmatched sonic performance, ProFX4v2 is truly the life of your live mix.

Features

2 extremely low-noise Mackie Vita™ mic preamps designed to add life to any input
All-new ReadyFX™ effects engine with 16 great-sounding effects like reverbs, delays and choruses
5-band graphic EQ for tuning mains or monitors
Aux output perfect for driving a monitor mix
2-band EQ (80Hz and 12kHz) on all channels
Directly connect guitar, bass and other instruments via Hi-Z input
100Hz low-cut filter and 48V phantom power on all mic channels
Stereo RCA tape I/O with input level control
Headphone output with separate level control
Legendary Mackie “Built-Like-A-Tank” design
Solid steel chassis protects your investment
Tough ABS side protection

Specifications

Noise Characteristics
Mic In to FX Send (Max Gain)	–128 dBu
Residual Output Noise ≤ 30 kHz	All outputs, master levels off, all channel levels off: –95 dBu All outputs, master levels unity, one channel level unity: –85 dBu
Frequency Response
Mic Input to Any Output	20 Hz to 40 kHz (gain at unity, +0 dB / –1 dB)
Distortion (THD+N)
Mic In to Main Out (+4 dBu Output)
Attenuation and Crosstalk
Adjacent Inputs @ 1 kHz	–80 dB
Inputs to Outputs @ 1 kHz	–80 dB
Fader Off @ 1 kHz	–80 dB
Common Mode Rejection Ratio (CMRR)
Mic In to Main Out	70 dB (max gain, 1 kHz)
Maximum Levels
All Inputs	+22 dBu
1/4	+22 dBu
All Other Outputs	+22 dBu
Impedances
Mic In	3.8 k Ω
All Other Inputs	≥ 20 k Ω
Tape Out	1 k Ω
Phones Out	25 Ω
All Other Outputs	120 Ω Unbalanced 240 Ω Balanced
Equalization
Low	±15 dB @ 80 Hz
High	±15 dB @ 12 kHz
Low Cut Filter	18 dB/octave @ 100 Hz
Maximum Voltage Gain (EQ Flat)	±15 dB @ 2.5 kHz
Mic Input Channel To	Insert Output: 50 dB Tape Output: 60 dB 1/4" Main Output: 70 dB Monitor Send: 76 dB FX Send: 75 dB
Mono Line Input Channel To	Tape Output: 40 dB Monitor Send: 56 dB FX Send: 55 dB
Stereo Line Input Channel To	Tape Output: 30 dB Monitor Send: 46 dB FX Send: 45 dB
Tape Input To	Main Output: 30 dB
USB Input To	Main Output: 30 dB16
Digital Effects
I/O	Mono Input, Stereo Output
Number of Presets	16
Graphic EQ
Frequency Centers	80, 250, 800, 2.5k, 8k
Gain	±15 dB
Phantom Power	48 VDC to all Mic channels simultaneously
Power Requirements	Class I Hard-Wired Wall Wart 12VDC @ 1.5A
Dimensions (H x W x D)	2.9" (73 mm) x 8.7" (220 mm) x 10.1" (256 mm)
Weight	3.2 lbs (1.4 kg)
