RCF P3108 8" 300W Weatherproof 2-Way 125 dB High Output Wide-Dispersion Loudspeaker

By RCF

RCF P3108 8" 300W Weatherproof 2-Way 125 dB High Output Wide-Dispersion Loudspeaker

Write a Review

Part #:

13000198

Model #:

P3108

Current Stock:

Availability: Usually arrives in 5-9 business days.

Quantity:

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The RCF P3108 is an 8" weatherproof, 2-way wide-dispersion loudspeaker offering substantial power and efficiency. The cabinet full UV protected, molded in medium density polyethylene for a variety of professional indoor or outdoor applications.

Description

The P3108 is a weatherproof full range, wide-dispersion, two-way loudspeaker system for offering substantial power and efficiency for a variety of professional indoor or outdoor applications. The high-frequency section is a constant directivity CMD horn loaded with a 1" RCF Precision compression driver with a 1.5" diaphragm assembly for smooth, wide dispersion. The low-frequency transducer is an 8" woofer with a 2.5" voice coil.

The cabinet is a single piece rotational molded in medium density polyethylene, full UV protected. The cabinet is equipped with 4xM8 brass inserts and stainless steel U-Bracket. The front logo is in aluminum and rotatable. The grille is in custom perforated aluminum with open-cell fibers and water repellent woven fabric backing. P 3108 is suitable for indoor and outdoor applications/installations, it meets the requirements of IP 55 code (International Protection Rating).

Features

Weatherproof cabinet IP 55
Aluminum grill
One 8" high-output LF transducer with 2.5" voice coil
One RCF Precision 1" Compression Driver with 1:5" voice coil
90° x 60° constant directivity horn
Built-in passive crossover
2° x 15° enclosure sides for array configurations
4 brass suspension points (M8)
Input connector 4 pole Amphenol IP 67
Mounting hardware 304 stainless steel, highly resistant to corrosion and oxidation

Specifications

Power Section
Frequency Response -10 dB	80 Hz ÷ 20000 Hz
Max SPL @ 1m	125 dB
Horizontal Coverage Angle	90°
Vertical Coverage Angle	60°
Directivity Index Q	11
System Sensitivity	94 dB
Nominal Impedance	8 Ω
Power Handling	300W RMS
Peak Power Handling	1200W Peak
Protections	Dinamyc
Crossover Frequencies	1800 Hz
Transducers
Compression Driver	1" HF driver, 2.5" voice coil
Nominal Impedance	8 Ω
Input Power Rating	25W AES
Sensitivity	109 dB
Woofer	8" woofer, 2.5" voice coil
Nominal Impedance	8 Ω
Input Power Rating	300W AES
Sensitivity	95 dB
Cabinet Material	Polyethylene rotomoulded
Hardware	4 x M8 + U-bracket and pair of spacers
Grille	Custom perforated aluminium grille with open-cell fiber and water repellent woven fabric backing
Color	Gray
Dimensions (H x W x D)	10.47" (266 mm) x 19.41" (493 mm) x 9.84" (250 mm)
Net Weight	23.37 lbs (10.6 kg)
