Shure MXW6X/O Omnidirectional Black Boundary Transmitter
The MXW6X/O is a sleek black, low-profile boundary microphone transmitter designed for the Microflex Wireless neXt system. Equipped with an omnidirectional condenser capsule, it delivers natural, full-range audio capture from all directions, making it ideal for conference tables, collaborative discussions, and multi-speaker environments.
Built for professional conferencing applications, the MXW6X/O provides reliable wireless performance, AES-256 encryption for secure communications, and advanced rechargeability. Its integrated lithium-ion battery delivers up to 17 hours of continuous use and recharges quickly when docked. Features like programmable mute control, out-of-range alerts, and earphone monitoring ensure seamless operation in modern meeting spaces.
With flexible placement, intuitive controls, and compatibility with Shure's networked charging and control ecosystem, the MXW6X/O offers premium sound quality, ease of use, and long-lasting reliability for today's dynamic conferencing needs.
- Features
Features
- Low-profile boundary microphone transmitter in a sleek black finish with omnidirectional capsule
- 360'° audio pickup for conference tables and group discussions
- Compatible with Microflex Wireless neXt systems
- Up to 17 hours of continuous operation with SB906 rechargeable battery
- AES-256 encryption ensures secure, private audio transmission
- Programmable mute button with push-to-talk, push-to-mute, or toggle modes
- Remote mute/unmute and monitoring via room control systems
- Adjustable transmit power for reliable wireless coverage up to 160 ft (50 m)
- Out-of-range alert to prevent lost connections
- Earphone jack for translation, cueing, or monitoring audio
- Information screen with battery runtime, room assignment, and system status
- Quick recharge via docking station
- Durable, low-profile housing ideal for modern conference environments
- Specification
Internal Microphone Input Omnidirectional Condenser Capsule Frequency Response (Mic) 27 Hz ‒ 19 kHz (+3 dB / -3 dB) Dynamic Range (Mic) 112 dB (A-weighted), 110 dB (unweighted), typical Headphone Output – Max Level -1 dBV (Volume = 100%) Headphone Frequency Response 27 Hz – 19 kHz (+0.5 dB / -3 dB) Headphone Dynamic Range 100 dB (A-weighted), 98 dB (unweighted), typical Headphone Load Impedance >8 kΩ, typical Max Headphone Output Power 1.5 mW (8Ω load, 1 kHz sine wave) Short-Circuit Protection Yes (headphone outputs protected) Wireless Range Up to 160 ft (50 m) Mute Functionality Programmable (push-to-talk, push-to-mute, toggle, or remote) Finish Black Encryption AES-256 (always on) Battery Type Shure SB906 Rechargeable Li-Ion Battery Life Up to 17 hours Battery Charge Time 3 hours (docked in APXD2 / NDX4/8/4G/8G) Dimensions (H x W x D) 4.66" (118.43 mm) x 1.85" (46.99 mm) x 1.03" (26.10 mm) Weight (with Battery) 0.25 lbs (0.12 kg) - Documents
