SoundTube IPD-CM82-BGM-II 8-Inch IP-Addressable Dante-Enabled In-Ceiling Speaker

The IPD-CM82-BGM-II is an 8" coaxial in-ceiling speaker designed for IP-addressable audio networks using Dante and AES67 protocols. It features an 8" polypropylene woofer with butyl rubber surround and a 1" silk dome tweeter, delivering consistent mid-range clarity and broad high-frequency coverage via BroadBeam Ring technology. Housed in a sealed steel backcan with a tuned port, it provides bass response down to 55 Hz (±10 dB) for full, rich sound.

Power, audio, and control are delivered through a single CAT5 or CAT6 cable using PoE (Power over Ethernet). Each speaker can be monitored and zoned via SoundTube software, with real-time status reporting for reliable operation. Installation is quick and secure using the SpeedWing mounting system and color-coded tile bridge for drywall or drop-tile ceilings.

This model features a paintable white steel grille for a clean, professional appearance, and optional pre-construction brackets are available for new construction. It is UL 60065 and UL 2043 listed, making it ideal for commercial, retail, hospitality, and distributed audio applications requiring professional-quality IP-addressable audio.

Features

Features

IP-addressable in-ceiling speaker compatible with Dante and AES67 networks
8" polypropylene woofer with butyl rubber surround and 1" silk dome tweeter
BroadBeam Ring technology for wide, smooth off-axis performance
Tuned port baffle for added bass response down to 55 Hz (±10 dB)
Power, audio, and control via single CAT5/CAT6 cable with 40 W PoE support
Real-time monitoring and reporting via SoundTube software
SpeedWing mounting system adaptable to ceiling thickness 0.035" (0.9 mm) - 2.5" (63.5 mm)
White, paintable steel grille for clean ceiling aesthetics
UL 60065 and UL 2043 listed for safety and reliability
Ideal for commercial, retail, hospitality, and distributed audio systems

Specification

Woofer Driver	8" Polypropylene Cone w/ Butyl Rubber Surround
Tweeter Driver	1" Silk Dome w/ BroadBeam Ring
Frequency Response (± 3 dB)	70 Hz - 18 kHz
Frequency Response (± 10 dB)	55 Hz - 22 kHz
Network Type: High Pass	12 dB per octave 2nd order
Low Pass Crossover	12 dB per octave 2nd order
Low Frequency Voice Coil	1" (25.4 mm)
Directivity Factor (Q)	5.4 and 7.2
Directivity Index (DI)	5.5 dB and 8.6 dB
Crossover Frequency	3.0 kHz
Source Inputs	RJ45 Ethernet Port
Enclosure Properties	ABS, Steel
Grille Properties	Standard-Flange, Friction-Fit, White, Paintable, Painted, Steel
Included Accessories	Conduit Clamp, Cover Plate, Grille, Paint Mask
Color	White
Certifications	CE, RoHS, UL2043, UL60065, ETL-C/US
Max. Ceiling Thickness	1.6" (40.6 mm)
Minimum Ceiling Thickness	0.04" (0.9 mm)
Cutout Width/Diameter	10.5" (266.7 mm)
Backcan Dimensions (H x Dia)	8" (203.2 mm) x 9.67" (245.6 mm)
Visible Dimensions (H x Dia)	0.34" (8.6 mm) x 11.75" (298.5 mm)
Weight	9 lbs (4.1 kg)
Shipping Weight	11 lbs (4.99 kg)
