| Color |
Black and silver |
| Enclosure |
Shatter resistant PC/ABS plastic |
| Battery type |
Li Polymer with smart charge built into transceiver |
| Battery life |
Up to 14hrs talk time per charge |
| Charge time |
5hrs. TFP 045 with cable and international adaptersOptional two-bay charger CHG 102 |
| Channels |
Up to 15 simultaneous channels (Interpretation mode),Up to 4 simultaneous groups (2 way mode) |
| Operating frequencies |
2.4GHz (ISM band) 2.402 – 2.476GHz FHSS |
| Frequency response |
150 – 11KHz |
| S/N ratio |
69dB (A weighted) |
| THD |
0.33 % |
| Microphone input |
Internal microphone (disabled when MIC jack engaged) and 3.5mm stereo jack |
| Microphone input |
(tip/sleeve) with electret microphone bias, adjustable gain with 63dB range. |
| Audio output |
Max SSPL 90 111.8dB (EAR 013), 116.8dB (EAR 041) |
| Audio output |
Internal speaker (disabled when ear jack engaged), 16mW @ 33Ω |
| Range |
Up to 100ft outdoors and 200ft indoors |
| Modulation |
GFSK, binary CDMA |
| RF output |
14dBm Max |
| Security code |
87 bit encryption |
| Controls |
Front push buttons for volume up/down, quick group select, menu access and selection |
| Controls |
MIC on/off, power on/off, tone control, side-tone adjustment, SLOC access and Secure Key access |
| Controls |
System reset button (rear of unit). |
| Output |
3.5mm stereo/mono jack 30 pin charging jack |
| Side tone |
Adjustable: Off (0dB), -6dB, -12dB below volume |
| Speaker |
Internal speaker (disabled when ear jack is engaged) |
| Indicators |
LCD (Group, channel, volume level, battery status, mode, signal strength) |
| LED’s |
Red LED around talk button when enabled. Amber LED signifying voting feature activated. |
| Maximum presenters |
Two presenters at any given time |
| Dimensions (H x W x D) |
4.1" (103 mm) x 2.4" (62 mm) x 0.4" (11 mm) |
| Weight |
0.18 lb (0.08 kg) including battery |
| Frequency Band |
2.4 GHz (ISM band) |
| Modulation |
GFSK digital transmission |
| Range |
Up to 100 ft outside, Up to 200 ft inside |
| Multi Channel |
Up to 15 simultaneous channels (one way mode) |
| Case Material |
Black ABS Plastic |
| Battery Life |
Alkaline Disposable (BAT 010-2): Up to 27 hrs, NiMH Rechargeable (BAT 022-2): Up to 21 hrs |
| Battery Type |
2 x AAA Alkaline or NiMH |
| Power Save |
Auto Sleep Mode after 1 min of no RF signal |
| Frequency Response |
150 Hz – 11 kHz |
| S/N Ratio |
65 dB (A weighted) |
| THD |
0.45% |
| Antenna |
Internal |
| Output |
60 mW, 3.5 mm stereo jack with mono output for Headphones/Earphones, Back Speaker |
| Controls |
Power, Volume +/-, Channel +/-, Setup, Battery Type |
| Display |
LCD shows status: Battery Level, RSSI, Group/Channel |
| Indicators |
Red LED - blinks when charging, Green LED - stays on when charged |
| Docking Connector |
30-pin iPod Style for charging and audio out |
| Compatible Transmitter |
DLT 100 |
| Temp. Range |
32° – 122°F (0° to 50°C) |
| Chargers |
CHG 102, CHG 1012, Digi-Dock |
| Dimensions |
2.36” W x 3.54” H x 0.63” D (60 mm x 90 mm x 16 mm) |
| Weight |
0.11 lb (0.05 kg) without batteries |
| Color |
Black |
| Cord |
39" |
| Phantom Powered |
No |
| Nominal Impedance |
32Ω |
| Freq. Response |
150 - 18kHz |
| Pick-Up Pattern |
Cardiod |
| Transducer Type |
Electret Cond |
| Sensitivity |
105dB EAR |
| Replacement Windscreen |
WND 008 |
| Replacement Earpad |
EAR 035 |
| Plug |
2 x 0.14" (3.5 mm) |
| Weight |
0.16 lb (0.07 kg) |
| Style |
Around-ear speaker |
| Plug |
3.5mm mono |
| Cord |
39” |
| Driver Size |
23 mm |
| Nominal Impedance |
32Ω |
| Freq. Response |
20 - 20kHz |
| Max Power Input |
30 mW |
| Sensitivity |
118 dB @ 1kHz |
| Weight |
15g |
| Enclosure |
CHG 1012: Black, ABS plastic with metal base |
| Power Supply Input |
TFP 047, 90-240 VAC input, 1.5 A max |
| Power Supply |
Universal DC adapter, 5 VDC - 6A output, center positive |
| Charging Time |
5 hours nominal |
| Unit Capacity |
12 Units |
| Indicators |
Charge status indicators on DLT 100 |
| CHG 1012 PRO Case Dimensions (H x W x D) |
6.75” (171 mm) x 14.0” (356 mm) x 18.0” (457 mm) |
| CHG1012 PRO Weight |
9.4 lbs (4.26 kg), including power supply |
| Dimensions (H x W x D) |
4.38" (111 mm) x 2.75" (70 mm) x 0.5" (13 mm) |
| Weight |
0.11 lb |
