Shure MXW6XW/O Omnidirectional Wireless Boundary Microphone Transmitter

By Shure

Shure MXW6XW/O Omnidirectional Wireless Boundary Microphone Transmitter - White

Name: Shure MXW6XW/O Omnidirectional Wireless Boundary Microphone Transmitter - White
Brand: Shure
SKU: SHURE-MXW6XW/O=-Z10
Price: 737 USD
Availability: InStock

Write a Review

Part #:

MXW6XW/O=-Z10

Model #:

MXW6XW/O

Current Stock:

Availability: Usually arrives in 5-9 business days.

Quantity:

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The Shure MXW6XW/O is a white omnidirectional boundary microphone transmitter with 360° voice pickup. With 17-hour battery life, AES-256 encryption, and flexible mute control, it ensures clear, secure audio for professional conferencing.

Description

Shure MXW6XW/O Omnidirectional White Boundary Transmitter

The MXW6XW/O omnidirectional boundary microphone transmitter delivers clear, natural audio capture in a low-profile form factor. Designed for boardrooms, classrooms, and collaborative spaces, its omnidirectional microphone element provides 360° voice pickup, making it ideal for roundtable discussions and multi-talker environments.

With up to 17 hours of continuous operation from the included SB906 rechargeable lithium-ion battery, the MXW6XW/O is engineered for reliability in long meetings. Features such as a programmable mute button, room control system integration, out-of-range alerts, and AES-256 encryption ensure dependable and secure performance. The sleek white housing blends seamlessly into modern conference settings while delivering Shure's trusted wireless technology.

Features

White low-profile boundary microphone transmitter
Omnidirectional condenser capsule with 360° audio capture
Up to 17 hours of runtime with SB906 rechargeable battery
Programmable mute button (push-to-talk, push-to-mute, push on/off)
Remote mute/unmute control via room system integration
Out-of-range alert for dependable operation
Adjustable transmit power with up to 160 ft (50 m) coverage
Always-on AES-256 encryption for secure audio
3.5 mm earphone jack for monitoring translation, cueing, or program audio
LCD screen displays battery status, room assignment, and more
Compatible with Microflex Wireless neXt systems

Specifications

Internal Microphone Input	Omnidirectional Condenser Capsule
Frequency Response (Mic)	27 Hz ‒ 19 kHz (+3 dB / -3 dB)
Dynamic Range (Mic)	112 dB (A-weighted), 110 dB (unweighted), typical
Headphone Output – Max Level	-1 dBV (Volume = 100%)
Headphone Frequency Response	27 Hz – 19 kHz (+0.5 dB / -3 dB)
Headphone Dynamic Range	100 dB (A-weighted), 98 dB (unweighted), typical
Headphone Load Impedance	>8 kΩ, typical
Max Headphone Output Power	1.5 mW (8Ω load, 1 kHz sine wave)
Short-Circuit Protection	Yes (headphone outputs protected)
Wireless Range	Up to 160 ft (50 m)
Mute Functionality	Programmable (push-to-talk, push-to-mute, toggle, or remote)
Finish	White
Encryption	AES-256 (always on)
Battery Type	Shure SB906 Rechargeable Li-Ion
Battery Life	Up to 17 hours
Battery Charge Time	3 hours (docked in APXD2 / NDX4/8/4G/8G)
Dimensions (H x W x D)	4.66" (118.43 mm) x 1.85" (46.99 mm) x 1.03" (26.10 mm)
Weight (with Battery)	0.25 lbs (0.12 kg)
