Yamaha's VXC-F low-profile ceiling speakers allow you to streamline the installation process for commercial spaces and seamlessly integrate high-quality audio into a restaurant, retail, or professional environment. Featuring a renovated speaker unit that's optimally tuned for music playback, the VXC-F's lightweight construction and flexible design can easily adapt to the strictest installation limitations, ensuring superb audio wherever they're placed.
Cutting-edge technology in the speaker units and resin enclosures allows an extraordinary degree of acoustic design freedom, resulting in refined, natural music reproduction at any volume level without the midrange distortion that often plagues speakers of this type. The VXC-F's speaker unit size and back box volume have also been matched to achieve well-balanced reproduction from low to high frequencies - even at low output levels.
The VXC-F ceiling speakers feature low profile back boxes, reduced weight, and mechanical features that contribute to significantly safer, faster installation. And since these models support both low-impedance and high-impedance connection, the need for extra stock is minimized and systems can be designed to meet the requirements of any application.
- Features
Features
- 4.5” full-range speaker unit
- Engineered for optimum BGM reproduction
- Wide coverage allows a single speaker to cover a wide area
- Direct support for low-impedance or high-impedance connections
- Low-profile design facilitates installation in limited ceiling spaces
- Built-in carrying band increases safety during installation
- Anti-drop tab mechanism provide secure temporary positioning during installation
- Double-threaded speaker clamp screws for speedy tightening
- Paintable grilles with magnetic catches
- Available in Black and White
- Specification
Frequency range (-10dB) 60 Hz - 20 kHz (Half-space:2ϖ) Nominal coverage 130° conical (Half-space :2ϖ) Components (LF-HF) 4.5” Full range unit NOISE 40 W PGM 80 W PEAK 160 W Nominal impedance 8 Ω Transformer taps - 100V 30 W, 15 W, 7.5 W, 3.8 W Transformer taps - 70V 30 W, 15W, 7.5 W Sensitivity (1W; 1m on axis) 89 dB SPL (Half-space:2ϖ) Peak (Calculated) 111 dB SPL (1m, Calculated based on power rating and sensitivity, exclusive of power compression) I/O connectors Euroblock (4 pin) × 1 (input: +/-, loop-thru: +/-) Protection circuit (Load protection) Full-range power limiting to protect network and transducers Finish VXC5F: Black (approx. Munsell N3), VXC5FW: White (approx. Munsell N9.3) Accessories O-ring, Tile Rail, Cutout Template, Euro Block (4pin), Terminal Cover Certificate UL1480, NFPA70, CE, EAC, RoHS Others Conduit tube: Ø15.4 mm - Ø21.3 mm Packaging Packaged in pairs Diameter 12-13/16" (324 mm) Cutout size Ø11-1/4" (Ø285 mm) Depth 5-11/16" (143 mm) Net Weight 6.8 lbs (3.1 kg) Shipping Weight 25 lbs (11.34) - Documents
