Yamaha DXS12 12 inch Active Subwoofer (Discontinued)

Yamaha DXS12 12 inch Active Subwoofer (Discontinued)

Name: Yamaha DXS12 12 inch Active Subwoofer (Discontinued)
Brand: Yamaha
SKU: YAMAHA-DXS12
Price: 699.99 USD
Availability: OutOfStock

Write a Review

Part #:

DXS12

Model #:

DXS12

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The Yamaha DXS12 12" 600W Active Subwoofer is an extremely compact and powerful subwoofer that provides rock-solid bass and consistent performance.

Description

The DXS Series are compact, high-output, powered subwoofers that match perfectly with DSR, DXR and DBR full-range powered loudspeakers, and feature intelligent DSP technologies that enhance the versatility in its performance.

The DXS Series has a band-pass design that produces extremely high SPL by drastically reducing the distortion. The DXS features a customized, high-power handling woofer with superior damping for a clean, accurate delivery of the massive power produced by a 950W Class-D high-efficiency amplifier. What’s more, Yamaha’s formidable DSP technologies are perfectly utilized in the DXS Series for precise tuning of filters and low-frequency response, as well as high-grade protection functions that ensure all components perform to the full limit of their potential. The unmistakable result is clearly defined, powerful bass frequencies that will take your sound system to new heights... and depths.

Features

Portable 12" subwoofer with 600-watt RMS power amp
12" long-throw speaker with a 2.5" voice coil for superb bass response
47Hz-160Hz frequency range is ideal for small- to medium-sized rooms
Built-in D-XSUB processing allows you to extend the frequency response even lower
Wooden cabinet is durable and acoustically optimized for maximum sound quality

Specifications

Frequency Range (-10dB)	47Hz - 160Hz
Components (LF)	Diameter: 12" cone, Voice Coil: 2.5"
Output power	Dynamic: 950W / Continuous: 600W
Maximum output level (1m; on axis)	131dB SPL
I/O connectors	INPUT: XLR-3-31 x2 , THRU: XLR3-32 x 2 (Parallel with INPUT)
Processors	D-XSUB: BOOST, XTENDED-LF, OFF
Power requirements	100V - 240V, 50Hz/60Hz
Power consumption	120W
Pole socket	35mm (Top x 1)
Material	Wood (Paint, Black)
Dimensions (H x W x D)	22 1/8" (563 mm) x 15 5/8" (397 mm) x 23 3/8" (594 mm)
Weight	72.8 lbs (33.0 kg)
