JBL Control 414C/T 4" 2-Way Coaxial Ceiling Loudspeakers with 130° Coverage - Pair

JBL Control 414C/T 4" 2-Way Coaxial Ceiling Loudspeakers

More Views

JBL Control 414C/T 4" 2-Way Coaxial Ceiling Loudspeakers with 130° Coverage - Pair

Part # JBL-C414C/T-U

Model # Control 414C/T

The JBL Control 414C/T 4" 2-way coaxial ceiling loudspeakers deliver premium full-range sound with wide 130° coverage, high fidelity, and low distortion. Their sleek bezel-less design and easy installation make them perfect for commercial and professional audio environments.

Availability:

Qty:

Description

Details

JBL Control 414C/T 4-Inch Coaxial Ceiling Loudspeakers

The Control 414C/T 4" 2-way coaxial ceiling loudspeakers deliver exceptional clarity and smooth, full-range sound in a refined, space-saving design. As part of the JBL Control 400 Standard Coverage Series, each speaker features a 100 mm (4") woofer and 20 mm (0.75") soft-dome tweeter mounted coaxially in a ported baffle, with an integrated backcan for simple, secure installation. The 130° wide coverage ensures uniform audio quality both on and off axis, making the Control 414C/T ideal for use in cafes, retail stores, offices, hotels, classrooms, and other commercial or institutional settings.

With a frequency response of 65 Hz - 20 kHz and high power handling (30W nominal, 120W peak at 8Ω), these speakers provide low-distortion, high-fidelity sound. The built-in 25W multi-tap transformer supports 70V/100V distributed systems, while the 8Ω direct mode allows parallel wiring of two speakers on a 4Ω amplifier channel.

Designed with aesthetics and functionality in mind, the Control 414C/T features a stylish, paintable, bezel-less grille that attaches magnetically for easy access and maintenance. A pre-attached safety tether and included C-ring, tile rails, and cutout template simplify installation. The system is UL 1480A and UL 2043 listed for safety compliance and pairs perfectly with the Control 419CS/T subwoofer for extended low-frequency performance.

Features

Features

Pair of 4" (100 mm) 2-way coaxial ceiling loudspeakers
Coaxially mounted 4" woofer and 0.75" soft-dome tweeter
Wide 130° coverage for consistent sound on and off axis
25W multi-tap transformer for 70V/100V distributed systems
Low-distortion, high-fidelity performance for clear, balanced audio
Sleek, paintable bezel-less grille with magnetic attachment and safety tether
Includes backcan, C-ring, tile rails, and cutout template for fast installation
UL 1480A and UL 2043 listed for commercial applications
Perfect for retail, hospitality, corporate, and educational spaces
Compatible with JBL Control 419CS/T subwoofer for enhanced bass

Specification

Frequency Range (-10 dB)	65 Hz - 20 kHz
Frequency Response (±3 dB)	83 Hz - 20 kHz
Power Capacity	90W Continuous Program (2 hrs) 45W (180W Peak), Continuous Pink Noise (2 hrs) 30W (120W Peak), Continuous Pink Noise (100 hrs)
Sensitivity	86 dB
Nominal Coverage Angle	130° conical
Directivity Factor (Q)	4.0
Directivity Index (DI)	6.0 dB
Rated Maximum SPL	103 dB continuous pink noise (109 dB peak)
Nominal Impedance	8Ω
Minimum Impedance	7.0Ω at 290 Hz
Transformer Taps	70V: 25W, 12.5W, 6.3W & 3.2W 100V: 25W, 12.5W, 6.3W
Recommended Protective High-Pass Filter Frequency	70 Hz (24 dB/oct LR)
Transformer Insertion Loss	0.7 dB @ 3.2W; 0.7 dB @ 6.3W; 0.7 dB @ 12.5W; 0.8 dB @ 25W
Maximum Input Voltage	17.7V RMS, 35.4V Peak (2hrs at 8Ω Input)
LF Driver	4" (100 mm) with paper cone, Polymerized Styrene Butadiene Rubber surround.
HF Driver	0.75" (20 mm) with highly damped treated soft-dome, neodymium magnet assembly, polyimide voice coil, wide dispersion waveguide.
Enclosure Material	Backcan: Powder-coated formed steel Baffle: PC/ABS, flammability rated UL 94 5VB
Grille	White (RAL9003)
Dimensions (Dia x H)	8.1" (203 mm) x 7.4" (186 mm)
Net Weight (ea)	5.51 lbs (2.50 kg)
Shipping Weight (Pair)	20.99 lbs (9.52 kg)
