JBL Control 418C/T 8" 2-Way Coaxial Ceiling Loudspeakers with 100° Coverage - Pair

JBL Control 418C/T 8" 2-Way Coaxial Ceiling Loudspeakers

More Views

JBL Control 418C/T 8" 2-Way Coaxial Ceiling Loudspeakers with 100° Coverage - Pair

Part # JBL-C418C/T-U

Model # Control 418C/T

The JBL Control 418C/T delivers high-fidelity sound with an 8" coaxial woofer and 1" soft-dome tweeter. Featuring 100° coverage, 70V/100V or 8Ω operation, and a sleek bezel-less grille, it provides powerful, full-range audio for commercial and institutional environments.

Availability:

Qty:

Description

Details

JBL Control 418C/T 8-Inch 2-Way Coaxial Ceiling Loudspeakers

The Control 418C/T is a high-performance 8" 2-way coaxial ceiling loudspeaker engineered for superior sound quality in commercial installations. Equipped with a 200 mm (8") woofer and a 25 mm (1") soft-dome tweeter mounted coaxially, it delivers balanced, full-range audio with low distortion and impressive clarity. With a wide 57 Hz - 20 kHz frequency response, 92 dB sensitivity, and a high 360W peak power rating, the Control 418C/T ensures outstanding performance for background music, paging, and multimedia applications.

Designed for both distributed and low-impedance systems, the Control 418C/T supports 70V/100V operation via a 60W multi-tap transformer as well as an 8Ω direct setting. The 100° coverage pattern ensures consistent, even sound distribution across large spaces such as restaurants, retail stores, airports, classrooms, hotels, and conference centers.

The sleek, bezel-less magnetic grille integrates elegantly into any room design and is paintable to match decor. A pre-attached backcan, C-ring, and tile rails are included for fast installation, while the integrated safety tether ensures secure mounting. UL 1480A and UL 2043 listings guarantee safety compliance for commercial environments. For enhanced bass performance, pair the Control 418C/T with the JBL Control 419CS/T subwoofer for a complete, professional-grade ceiling sound solution.

Features

Features

8" (200 mm) coaxial woofer and 1" (25 mm) soft-dome tweeter for full-range clarity
100° wide coverage ensures consistent sound dispersion
High power handling: 90W continuous, 360W peak at 8Ω nominal
60W multi-tap transformer for 70V/100V distributed systems
Broad 57 Hz - 20 kHz frequency range and 92 dB sensitivity
Low distortion and wide bandwidth for high-fidelity performance
Sleek bezel-less magnetic grille, paintable, and easy to install
Pre-attached backcan, C-ring, and tile rails included for quick setup
UL 1480A and UL 2043 listed for commercial safety compliance
Compatible with JBL Control 419CS/T subwoofer for added bass extension

Specification

Frequency Range (-10 dB)	57 Hz - 20 kHz
Frequency Response (±3 dB)	74 Hz - 19 kHz
Power Capacity	270W Continuous Program (2 hrs) 135W (540W Peak), Continuous Pink Noise (2 hrs) 90W (360W Peak), Continuous Pink Noise (100 hrs)
Sensitivity	92 dB
Nominal Coverage Angle	100° conical
Directivity Factor (Q)	6.2
Directivity Index (DI)	7.9 dB
Rated Maximum SPL	113 dB continuous pink noise (119 dB peak)
Nominal Impedance	8Ω
Minimum Impedance	6.9Ω at 200 Hz
Transformer Taps	70V: 60W, 30W, 15W & 7.5W 100V: 60W, 30W, 15W
Recommended Protective High-Pass Filter Frequency	60 Hz (24 dB/oct LR)
Transformer Insertion Loss	0.6 dB @ 7.5W; 0.8 dB @ 15W; 0.9 dB @ 30W; 0.9 dB @ 60W
Maximum Input Voltage	30V RMS, 61V Peak (2hrs at 8Ω Input)
LF Driver	8" (200 mm) with paper cone, Polymerized Styrene Butadiene Rubber surround.
HF Driver	1" (25 mm) with highly damped treated soft-dome, neodymium magnet assembly, polyimide voice coil, wide dispersion waveguide.
Enclosure Material	Backcan: Powder-coated formed steel Baffle: PC/ABS, flammability rated UL 94 5VB
Grille	White (RAL9003)
Dimensions (Dia x H)	12.6" (315 mm) x 11.3" (283 mm)
Net Weight (ea)	12.79 lbs (5.8 kg)
Shipping Weight (Pair)	39.07 lbs (17.72 kg)
