JBL Control 440CS/T 8" In-Ceiling Subwoofers with Built-In Passive Crossover - Pair

JBL Control 440CS/T 8" In-Ceiling Subwoofers

More Views

JBL Control 440CS/T 8" In-Ceiling Subwoofers with Built-In Passive Crossover - Pair

Part # JBL-C440CS/T-U

Model # Control 440CS/T

The JBL Control 440CS/T is a pair of high-power 8" in-ceiling subwoofers with built-in passive crossover. Featuring 100 W RMS (400W peak), 32 Hz-300 Hz frequency range, and 70V/100V transformer support, it delivers deep, low-distortion bass for satellite speaker systems.

Availability:

Qty:

Description

Details

JBL Control Control 440CS/T 8-Inch In-Ceiling Subwoofers

The Control 440CS/T is a premium pair of in-ceiling subwoofers designed to provide deep, high-fidelity bass for commercial and professional audio systems. Equipped with a 200 mm (8") long-excursion woofer and polymerized SBR surround, it delivers powerful low-frequency performance with minimal distortion. Its 32 Hz-300 Hz frequency range ensures full-bodied bass, making it ideal for restaurants, retail spaces, hotels, airports, and other distributed audio environments.

Featuring a built-in passive crossover, the Control 440CS/T can be used as part of a subwoofer-satellite system, supporting two or four satellite speakers to produce a wide-bandwidth, full-range audio experience. It can operate in low-impedance 8Ω mode or in 70V/100V distributed systems using the included 80W multi-tap transformer, providing versatility for different installation scenarios. The system’s copper-clad aluminum voice coil ensures high sensitivity and low distortion even at high output levels.

The bezel-less grille and integrated backcan allow the subwoofer to blend seamlessly into ceiling designs while simplifying installation. A C-ring support backing plate, pre-installed backcan, and paintable grille are included for quick, professional installation. Optional grilles are available in black (JBL-MTC-440BG) or square white (JBL-MTC-440SG). UL 1480A and UL 2043 listings make the Control 440CS/T a safe, reliable choice for commercial distributed audio applications.

Features

Features

Pair of 8" (200 mm) long-excursion woofers with polymerized SBR surround for powerful, low-distortion bass
Built-in passive crossover supports 2 or 4 satellite speakers for full-range system performance
High power handling: 100W continuous/400W peak
32 Hz-300 Hz frequency range for deep, accurate low frequencies
80W multi-tap transformer included for 70V/100V distributed systems
8Ω low-impedance operation allows paralleling up to 2 speakers per channel
Sleek bezel-less magnetic grille integrates seamlessly into ceilings; paintable
Pre-attached backcan, C-ring, and support plate for fast, secure installation
Optional accessory grilles available in black or square white
UL 1480A and UL 2043 certified for commercial safety compliance

Specification

Frequency Range (-10 dB)	32 Hz - 300 Hz
Frequency Response (±3 dB)	42 Hz - 180 Hz
Power Capacity	300W Continuous Program (2 hrs.) 15W (600W Peak), Continuous Pink Noise (2 hrs.) 100W (400W Peak) Continuous Pink Noise Power (100 hrs.)
Sensitivity	95 dB in ceiling near corner (π/2 loading) 92 dB in ceiling near wall (1π loading) 111 dB continuous pink noise (117 dB peak, 2 hrs., 2π loading)
Rated Maximum SPL	113 dB continuous pink noise (119 dB peak)
Nominal Impedance	8Ω
Minimum Impedance	6.9Ω at 92 Hz
Transformer Taps	70V: 80W, 40W, 20W & 10W 100V: 80W, 40W, 20W
Recommended Protective High-Pass Filter Frequency	45 Hz (24 dB/oct LR)
Transformer Insertion Loss	0.5 dB @ 10W; 0.5 dB @ 20W; 0.5 dB @ 40W; 0.6 dB @ 80W
Maximum Input Voltage	31.9V RMS, 63.8V Peak (2hrs at 8Ω Input)
Full-Range Driver	200 mm (8") treated paper cone with Polymerized Styrene- Butadiene Rubber surround, high-performance magnet, 38 mm (1.5 in) PESV voice coil on aluminum voice coil former.
Enclosure Material	Backcan: Powder-coated formed steel Baffle: PC/ABS, flammability rated UL 94 5VB
Grille	White (RAL9003)
Dimensions (Dia x H)	13.5" (342 mm) x 13.8" (351 mm)
Net Weight (ea)	19.22 lbs (8.72 kg)
Shipping Weight (Pair)	55.16 lbs (25.02 kg)
